Flexible Silicone Neon · Freebend

F N 1617F

Q: What is the FXN 1617 Freebend's shape and bend capability?

It measures 16 mm wide × 17 mm high and is a freebend profile, bending both horizontally and vertically.

Q: What are the FXN 1617 Freebend's minimum bend diameter and cut length?

Its minimum bending diameter is Ø300 mm , and it can be cut every 45.4 mm (1 unit).

Q: What colours and white temperatures does the FXN 1617 Freebend offer?

It is available in Red, Green, Blue, White and Dynamic White , with white from 2200K to 5700K (including 2400K and 5000K).

Q: What are the FXN 1617 Freebend's power, output and operating temperature?

It draws 8 W/m (R / G / B / W) or 12 W/m (DW) , delivers ≥620 lm/m , and operates from −40°C to +60°C .

Q: What warranty does the FXN 1617 Freebend carry?

The FXN 1617 Freebend carries a 5-year warranty .

The FXN 1617 Freebend is a flexible silicone neon for architectural and commercial work. It bends both horizontally and vertically in a single product, fitting around complex surfaces and curved geometries. RGBW output, IP68 housing, X-Stream control.

Colour Red · Green · Blue · W · DW
Output 120° beam · >620 lm/m
Build IP68 · Silicone
Control X-Stream · DMX · SPI

Configure Your Product View Specifications

Specifications Downloads Accessories Configurator FAQs

Key Specifications · FXN 1617F Freebend Flexible Neon

Electrical
Power Consumption	8 W/m (R, G, B, W) · 12 W/m (DW)
Operating Voltage	24 V DC
Operating Temperature	−40°C to +60°C (−40°F to +140°F)
Physical
Fixture Dimensions	(L) 1000 mm × (H) 17 mm × (W) 16 mm
Fixture Bending	Freebend (Horizontal & Vertical)
Min. Bending Diameter	Ø300 mm (H & V)
LEDs / m	154 LEDs/m (R, G, B, W) · 308 LEDs/m (DW)
Min. Cutting Length	45.4 mm (1 unit)
Weight/m	330 g/m
Optical
Beam Angle	120°
Lumen Output	≥620 lm/m (R, G, B, W at 3000K) · ≥310 lm/m (DW at 5700K)
CRI	≥90
Colour Range
White CCT	2200K 2400K 2700K 3000K 3500K 4000K 5000K 5700K
Control
Control Protocols	X-Stream DMX SPI
Ratings
Protection Ratings	IP68
Warranty	5 Years

Note: Standard specification summary for quick evaluation. Exact electrical values vary by colour option and power supply configuration. Contact us for full datasheet and variant-specific performance data.
