The FXN 1121 measures 11.5 mm wide × 21 mm high, in 1-metre lengths.
Fixtures
Hardware
Fixtures
Hardware
Flexible Silicone Strip
N
1121
The FXN 1121 is a dynamic, flexible lighting solution for bold, vibrant illumination. With rich RGBW colours and a bendable design, it seamlessly enhances architectural features, retail displays, and event spaces. Made from silicone and engineered for reliability with IP67 water resistance and IK08 impact protection.
| Electrical | |
|---|---|
| Power Consumption | 12 W/m (RGB, DW) · 15 W/m (W, RGBW, X-Stream) |
| Operating Voltage | 24 V DC |
| Operating Temperature | −40°C to +55°C (−40°F to +131°F) |
| Physical | |
| Fixture Dimensions | (L) 1000 mm × (H) 21 mm × (W) 11.5 mm |
| Fixture Bending | Horizontal Bending |
| LEDs Qty / Unit | 10 LEDs/unit (W, RGB, RGBW) · 20 LEDs/unit (DW) · 28 LEDs/unit (X-Stream) |
| LEDs Qty / m | 60 LEDs/m (W, RGB, RGBW) · 120 LEDs/m (DW) · 280 LEDs/m (X-Stream) |
| Min. Cutting Length | 166.7 mm (RGB, RGBW, DW, W) · 100 mm (X-Stream) |
| Min. Bending Diameter | Ø120 mm |
| Pixel Density | 6 px/m · 10 px/m (X-Stream) |
| Optical | |
| Beam Angle | 120° |
| Colour Range |
|
| White CCT |
2200K
2700K
3000K
3500K
4000K
5700K
|
| LED Type | EPISTAR SMD LED |
| LED Distance | 16.67 mm |
| Control | |
| Control Protocols |
X-Stream
DMX
SPI
|
| Ratings | |
| Protection Ratings |
IP67
IK08
|
Note: Standard specification summary for quick evaluation. Exact electrical values vary by colour option and power supply configuration. Contact us for full datasheet and variant-specific performance data.
FXN 1121 Flexible Neon Downloads
FXN 1121 Flexible Neon Accessories
Interactive Configurator
Fine-tune colour option, mounting profile, control protocol, and finish, then generate a build-ready FXN 1121 configuration for your installation.
